The multi-layer wrapping vacuum structure replaces the pearlescent sand insulation and eliminates the hidden danger of the lower layer of the insulation layer. Product features: 1. Multi-layer wrapping replaces pearlescent sand to eliminate the hidden danger of sinking; 2. Optional electronic scale, free you from the dispute and trouble of measurement.
Technical Introduction:
The multi-layer wrapping vacuum structure replaces the pearlescent sand insulation and eliminates the hidden danger of the lower layer of the insulation layer.
Technical Features:
1. Multi-layer bandaging replaces pearlescent sand to eliminate the hidden danger of sinking;
2. Optional electronic scale, free you from the dispute and trouble of measurement.
Main Specifications:
1. Working pressure: 0.2-3.0MPa
2. Effective volume: 2m³-200m³
Technical Parameters:
Model | Effective volume m ³ | Equipment empty weight kgs | Device sizel*w*h | |
CDL-3.5 | 3.5 | 3600 | ф2020×4300 |
|
CDL-5 | 5 | 4366 | ф2020×5080 |
|
CDL-10 | 10 | 6551 | ф2420×6145 |
|
CDL-15 | 15 | 9590 | ф2620×7050 |
|
CDL-20 | 20 | 11800 | ф2620×8700 |
|
CDL-30 | 30 | 17300 | ф3230×8600 |
|
CDL-50 | 50 | 26500 | ф3230×12480 |
|
CDL-100 | 100 | 58760 | ф3640×17510 |
|
CDL-200 | 200 | 86531 | ф3640×29700 |
