Fermentation gas CO2 recycling

Technical Introduction:

Fermentation gas generally refers to the high concentration of carbon dioxide tail gas released from the fermentation system of alcohol plants, breweries, sugar factories, etc., generally containing 90~99% CO2, as well as alcohols, aldehydes, methane, hydrogen, nitrogen, water vapor and other impurities, may contain a small amount of NO and grease. This system is washed with water. Water separation and special adsorbent combined to remove alcohols, aldehydes, lipids, NO, etc., and use drying, cooling, heat exchange and rectification column rectification to remove water, methane, hydrogen, nitrogen and other impurities, stored in the storage tank for user use.

Technical Features:

1. The whole set of equipment adopts a targeted design method, that is, different designs for the raw gas of different components of users, so as to minimize equipment investment and operating energy consumption while ensuring product function;

2. Concise equipment, small footprint, easy installation;

3. The control system adopts distributed control system (DCS system), which is simple to operate and can realize 24-hour continuous operation unattended.

4. The carbon dioxide contact part of the whole set of equipment is made of stainless steel, which has strong safety and stability.

Technical Parameters:
